Question
A ball is thrown vertically up with a velocity of 20m/s. Construct acceleration time and displacement time graph.
✓
Answer
u = 20ms-1, a = g ms-2 Time to reach the highest point, $\text{t}=\frac{\text{u}}{\text{g}}=2\text{ seconds}.$ Max. height $=\frac{1}{2}\text{g}\times4=20\text{m}$
