Question

Consider a given sample of an ideal gas $\Big(\frac{\text{C}_\text{P}}{\text{C}_\text{V}}=\gamma\Big)$ having initial pressure $P_0$ and volume $V_0.$

The gas is isothermally taken to a pressure $\frac{\text{P}_0}{2}$ and from there, adiabatically to a pressure $\frac{\text{P}_0}{4}.$ Find the final volume.
The gas is brought back to its initial state. It is adiabatically taken to a pressure $\frac{\text{P}_0}{2}$ and from there, isothermally to a pressure $\frac{\text{P}_0}{4}.$ Find the final volume.

✓

Answer

Initial pressure $= P_0$
Initial Volume $= V_0$
$\gamma=\frac{\text{C}_\text{P}}{\text{C}_\text{V}}$

Isothermally to pressure $=\frac{\text{P}_0}{2}$

$\text{P}_0\text{V}_0=\frac{\text{P}_0}{2}\text{V}_1$
$\Rightarrow\text{V}_1=2\text{V}_0$
Adiabetically to pressure $\frac{\text{P}_0}{4}$
$\frac{\text{P}_0}{2}(\text{V}_1)^\gamma=\frac{\text{P}_0}{4}(\text{V}_2)^\gamma$
$\frac{\text{P}_0}{2}(2\text{V}_0)^\gamma=\frac{\text{P}_0}{4}(\text{V}_2)^\gamma$
$\Rightarrow2^{\gamma+1}\text{V}_0^\gamma=\text{V}_2^\gamma$
$\Rightarrow\text{V}_2=2^\frac{(\gamma+1)}{\gamma}\text{V}_0$
$\therefore$ Final Volume $=2^\frac{(\gamma+1)}{\gamma}\text{V}_0$

Adiabetically to pressure $\frac{\text{P}_0}{4}$ to $P_0$

$\text{P}_0\times\big(2^{\gamma+1}\text{V}_0^\gamma\big)=\frac{\text{P}_0}{2}\times(\text{V}')^\gamma$
Isothermal to pressure $\frac{\text{P}_0}{4}$
$\frac{\text{P}_0}{2}\times2^\frac{1}{\gamma}\text{V}_0=\frac{\text{P}_0}{4}\text{V}''$
$\Rightarrow\text{V}''=2^\frac{(\gamma+1)}{\gamma}\text{V}_0$
$\therefore$ Final Volume $=2^\frac{(\gamma+1)}{\gamma}\text{V}_0$

Need a full question paper?

Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.

Start Generating Free

Explore more

Physics STD 12 Science question papers→Gujarat Board STD 12 Science question papers→Gujarat Board question paper generator→

Similar questions

An object 1.5 cm in size is placed on the side of the convex lens in the arrangement (a) above. The distance between the object and the convex lens is 40 cm. Determine the magnification produced by the two-lens system, and the size of the image.

→

Using Ampere's circuital law, obtain the expression for the magnetic field due to a long solenoid at a point inside the solenoid on its axis.
In what respect is a toroid different from a solenoid? Draw and compare the pattern of the magnetic field lines in the two cases.
How is the magnetic field inside a given solenoid made strong?

→

A monoenergetic electron beam with electron speed of $5.20 \times 10^6 ms^{–1}$ is subject to a magnetic field of $1.30 \times 10^{–4} T$ normal to the beam velocity. What is the radius of the circle traced by the beam, given e/m for electron equals $1.76 \times 10^{11}C\ kg^{–1}.$

→

A particle with a charge of 5.0 µC and a mass of 5$.0 \times 10^{-12}kg$ is projected with a speed of $1.0km s^{-1}$ in a magnetic field of magnitude 5.0mT. The angle between the magnetic field and the velocity is $\sin^{-1} (0.90).$ Show that the path of the particle will be a helix. Find the diameter of the helix and its pitch.

→

A capacitor of capacitance C is connected to a battery of emf $\in$ at t = 0 through a resistance R. Find the maximum rate at which energy is stored in the capacitor. When does the rate have this maximum value?

→

Using Biot-Savart’s law, derive an expression for the magnetic field at the centre of a circular coil of radius R, number of turns N, carrying current i.
Two small identical circular coils marked 1, 2 carry equal currents and are placed with their geometric axes perpendicular to each other as shown in the figure. Derive an expression for the resultant magnetic field at O.
