Question

Partha, a software engineer, lives in Jerusalem for his work. He lives in the most convenient area of the city from where bank, hospital, post office and supermarket can be easily accessed. In the graph, the bank is plotted as A(9, 5), hospital as B(-3,1) and supermarket as C(5,5) such that A, B, C form a triangle.

Based on the above given information, answer the following questions:
(i) Find the distance between the bank and the hospital.
(ii) In between the bank and the supermarket, there is a post office plotted at E which is their mid-point. Find the coordinates of E.
(iii) (a) In between the hospital and the supermarket, there is a bus stop plotted as D, which is their mid-point. If Partha wants to reach the bus stand from the bank, then how much distance does he need to cover ?
OR
(b) P and Q are two different garment shops lying between the bank and the hospital, such that $BP = PQ = QA$. If the coordinates of P and Q are $(1, a)$ and $(b, 3)$ respectively, then find the values of ' $a$ ' and ' $b$ '.

✓

Answer

(i) Distance between bank and hospital $=\sqrt{(-3-9)^2+(-1-5)^2}$
$=\sqrt{180}$ units or $6 \sqrt{5}$ units
(ii) Coordinates of E are $\left(\frac{9+5}{2}, \frac{5+(-5)}{2}\right)=(7,0)$
(iii) (a) Coordinates of D are $\left(\frac{-3+5}{2}, \frac{-1+(-5)}{2}\right)=(1,-3)$
Distance Partha need to cover $=\sqrt{(9-1)^2+(5-(-3))^2}$
$=\sqrt{128}$ units or $8 \sqrt{2}$ units
OR
(iii) (b) P is mid-point of BQ
$
\therefore a=\frac{-1+3}{2}=1
$
Q is mid-point of PA
$
\therefore b=\frac{1+9}{2}=5
$

Need a full question paper?

Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.

Start Generating Free

Explore more

More "Case study (4 Marks)" from Maths (Standard) 2024 Compartment Exams Set-1→Maths (Standard) 2024 Compartment Exams Set-1 — all question types→Maths STD 10 question papers→CBSE Board STD 10 question papers→CBSE Board question paper generator→

Similar questions

Read the text carefully and answer the questions:
Skysails is the genre of engineering science that uses extensive utilization of wind energy to move a vessel in the seawater.
The 'Skysails' technology allows the towing kite to gain a height of anything between $100$ metres $- 300$ metres.
The sailing kite is made in such a way that it can be raised to its proper elevation and then brought back with the help of a 'telescopic mast' that enables the kite to be raised properly and effectively.
Based on the following figure related to sky sailing, answer the following questions:

$(a)$ In the given figure, if $\sin \theta=\cos \left(\theta-30^{\circ}\right)$, where $\theta$ and $\theta-30^{\circ}$ are acute angles, then find the value of $\theta$.
$(b)$ What should be the length of the rope of the kite sail in order to pull the ship at the angle $\theta$ $($calculated above$)$ and be at a vertical height of $200 m$ ?
OR
What should be the length of the rope of the kite sail in order to pull the ship at the angle $\theta \ ($calculated above$)$ and be at a vertical height of $150 m$ ?
$(c)$ In the given figure, if $\sin \theta=\cos \left(3 \theta-30^{\circ}\right),$ where $\theta$ and $3 \theta-30^{\circ}$ are acute angles, then find the value of $\theta$.

Temper-proof tetra-packed milk guarantees both freshness and security. This milk ensures uncompromised quality, preserving the nutritional values within and making it a reliable choice for health-conscious individuals.

500 mL milk is packed in a cuboidal container of dimensions 15 cm x 8 cm x 5 cm. These milk packets are then packed in cuboidal cartons of dimensions 30 cm x 32 cm x 15 сm.
(i) Find the volume of the cuboidal carton.
(ii) (a) Find the total surface area of a milk packet.
OR
(b) How many milk packets can be filled in a carton?
(iii) How much milk can the cup (as shown in the Figure) hold?

An asana is a body posture, originally and still a general term for a sitting meditation pose, and later extended in hatha yoga and modern yoga as exercise, to any type of pose or position, adding reclining standing, inverted twisting and balancing poses. In the following figure, one can observe that poses can be related to representation of a quadratic polynomial.

(i) The shape of the poses shown is
(a) Spiral $\qquad$ (b) Ellipse $\qquad$ (c) Linear $\qquad$ (d) Parabola
(ii) The graph of the parabola representing polynomial $p(x)=a x^2+b x+c$ opens downward, if
(a) $a \geq 0$ $\qquad$ (b) $a=0$ $\qquad$ (c) $a<0$ $\qquad$ (d) $a>0$
(iii) The number of zeroes of the polynomial representing the graph in Fig. is
(a) 0 $\qquad$ (b) 1 $\qquad$ (c) 3 $\qquad$ (d) 2
(iv) The zeroes of the polynomial representing the graph in Fig. is
(a) $-2,3$ $\qquad$ (b) $2,-3$ $\qquad$ (c) $-2,6$ $\qquad$ (d) 2,3

→

Read the following text carefully and answer the questions that follow: A bird is sitting on the top of a tree, which is $80\ m$ high. The angle of elevation of the bird, from a point on the ground is $45^{\circ}$. The bird flies away from the point of observation horizontally and remains at a constant height. After $2$ seconds, the angle of elevation of the bird from the point of observation becomes $30^{\circ}$. Find the speed of flying of the bird.

$i.$ Find the distance between observer and the bottom of the tree?
$ii$. Find the speed of the bird?
$iii$. Find the distance between second position of bird and observer?
OR
Find the distance between initial position of bird and observer?

Read the following text carefully and answer the questions that follow:
Basant and Vinod lives in a housing society in Dwarka, New Delhi. There are two building in their housing society. The first building is 8 meter tall. One day, both of them were just trying to guess the height of the other multi-storeyed building. Vinod said that it might be a 45 degree angle from the bottom of our building to the top of multi-storeyed building so the height of the building and distance from our building to this multi-storeyed building will be same. Then, both of them decided to estimate it using some trigonometric tools. Let's assume that the first angles of depression of the top and bottom of an 8 m tall building from top of a multi-storeyed building are $30^{\circ}$ and $45^{\circ}$, respectively.

i. Now help Vinod and Basant to find the height of the multi-storeyed building.
ii. Also, find he distance between two buildings.

→

ABC construction company got the contract of making speed humps on roads. Speed humps are parabolic in shape and prevents overspeeding, minimise accidents and gives a chance for pedestrians to cross the road. The mathematical representation of a speed hump is shown in the given graph.

Based on the above information, answer the following questions.

The polynomial represented by the graph can be which polynomial?
The zeroes of the polynomial represented by the graph are?
If $\alpha$ and $\beta$ are the zeroes of the polynomial represented by the graph such that $\beta>\alpha,$ then $|8\alpha\ +\ \beta|= $
Or
The expression of the polynomial represented by the graph is?

Read the following text carefully and answer the questions that follow:
Karan went to the Lab near to his home for COVID 19 test along with his family members.
The seats in the waiting area were as per the norms of distancing during this pandemic (as shown in the figure).
His family member took their seats surrounded by red circular area.

i. What is the distance between Neena and Karan?
ii. What are the coordinates of seat of Akash?
iii. What will be the coordinates of a point exactly between Akash and Binu where a person can be?
OR
Find distance between Binu and Karan.

→

Quilts are available in various colours and design. Geometric design includes shapes like squares, triangles, rectangles, hexagons etc.
One such design is shown above. Two triangles are highlighted, $\triangle ABC$ and $\triangle PQR .$
Based on above information, answer the following questions:
$1.$ Which of the following criteria is not suitable for $\triangle ABC$ to be similar to $\triangle QRP ?$
$(a) \ \text{SAS} \ (b) \ \text{AAA}$
$(c) \ \text{SSS} \ (d) \ \text{RHS}$
$2.$ If each square is of length $x$ unit, then length $B C$ is equal to
$(a) \ x \sqrt{2}$ unit $(b) \ 2 x$ unit
$(c) \ 2 \sqrt{x}$ unit $(d)\ x \sqrt{x}$ unit
$3.$ Ratio $BC : PR$ is equal to
$(a) \ 2: 1 \ (b)\ 1: 4 $
$(c) \ 1: 2 \ (d)\ 4: 1$
$4. \operatorname{ar}( PQR ): \operatorname{ar}( ABC )$ is equal to
$(a) \ 2: 1 \ (b) \ 1: 4 $
$(c) \ 4: 1 \ (d) \ 1: 8$
$5.$ Which of the following is not true?
$(a) \ \triangle TQS \sim \triangle PQR \ (b) \ \triangle CBA \sim \Delta STQ $
$(c) \ \triangle BAC \sim \triangle PQR \ (d) \ \triangle PQR \sim \triangle ABC$

A backyard is in the shape of a triangle $\text{ABC}$ with right angle at $B$. $AB =7 m$ and $BC =15 m$. A circular pit was dug inside it such that it touches the walls $A C, B C$ and $A B$ at $P, Q$ and $R$ respectively such that $AP =x m$.

Based on the above information, answer the following questions:
$(i)$ Find the length of $AR$ in terms of $x$.
$(ii)$ Write the type of quadrilateral $\text{BQOR} $.
$(iii) \ (a)$ Find the length $PC$ in terms of $x$ and hence find the value of $x$.
OR
$(b)$ Find $x$ and hence find the radius $r$ of circle.

Kite festival is celebrated in many countries at different times of the year. In India, every year 14 th January is celebrated as International Kite Day. On this day many people visit India and participate in the festival by flying various kinds of kites. The picture given below, shows kites flying together.

In Fig. the angles of elevation of two kites (Points A and B) from the hands of a man (Point C) are found to be $30^{\circ}$ and $60^{\circ}$ respectively. Taking $A D=50 m$ and $B E=60 m$, find
(i) the lengths of strings used (take them straight) for kites $A$ and $B$ as shown in the figure.
(ii) the distance ' $d$ ' between these two kites.
