Question
Construct, if possible, a quadrilateral ABCD given AB = 6cm, BC = 3.7cm, CD = 5.7cm, AD = 5.5cm and BD = 6.1cm. Give reasons for not being able to construct it, if you cannot.
✓
Answer
Steps of construction:Step I: Draw AB = 6cm.
Step II: With A as the centre and radius 5.5cm, draw an arc.
Step III: With B as the centre and radius 6.1cm, draw an arc to intersect th arc drawn in Step II at D.
Step IV: With B as the centre and radius 3.7cm, draw an arc on the side.
Step V: With D as the centre and radius 5.7cm, draw an arc to intersect the arc drawn in Step IV at C.
Step VI: Join BD, DA, BC and CD. The quadrilateral ABCD so obtained is the required quadrilateral.
Need a full question paper?
Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.
Explore more
Similar questions
Mariam bought two fans for Rs. 3605. She sold one at a profit of 15% and the other at a loss of 9%. If Mariam obtained the same the same amount for each fan, find the cost price of each fan.
Draw a pie-diagram for the following data of the investment pattern in a five year plan:
|
Agriculture
|
Irrigation and Power | Small Industries |
Transport
|
Social service
|
Miscellaneous
|
|
14%
|
16%
|
29%
|
17%
|
16%
|
8%
|
Making use of the cube root table, find the cube root 34.2
Draw a histogram to represent the following data:
|
Monthly salary (in Rs.)
|
Number of teachers
|
|
5600-5700
|
8
|
|
5700-5800
|
4
|
|
5800-5900
|
3
|
|
5900-6000
|
5
|
|
6000-6100
|
2
|
|
6100-6200
|
3
|
|
6200-6300
|
1
|
|
6300-6400
|
2
|
The following table shows the percentages of buyers of four different brands of bathing soaps.
Represent the above data by a pie chart.
|
Brand
|
A | B | C | D |
|
Percentage of buyers
|
20%
|
40%
|
25% |
15%
|
Express product as a monomials and verify the result for $x=1, y=2$:
$\left(-x y^3\right) \times\left(y x^3\right) \times(x y)$
→$\left(-x y^3\right) \times\left(y x^3\right) \times(x y)$
Which of the following numbers are perfect squares?
- 484
- 625
- 576
- 941
- 961
- 2500
Use the given information and fill in the boxes with suitable numbers. Smt. Deepanjali purchased a house for Rs 7,50,000 from Smt. Leelaben through an agent. Agent has charged 2 % brokerage from both of them.
Draw a sufficiently large ∆ABC.
Draw medians; seg AR, seg BQ and seg CP of ∆ABC.
Name the point of concurrence as G.
Measure the lengths of segments from the figure and fill in the boxes in the following table.
\begin{tabular}{|l|l|l|}
\hline$I(A G)=$ & $I(G R)=$ & $I(A G): I(G R)=$ \\
\hline$I(B G)=$ & $I(G Q)=$ & $I(B G): I(G Q)=$ \\
\hline$I(C G)=$ & $I(G P)=$ & $I(C G): I(G P)=$ \\
\hline
\end{tabular}
→Draw medians; seg AR, seg BQ and seg CP of ∆ABC.
Name the point of concurrence as G.
Measure the lengths of segments from the figure and fill in the boxes in the following table.
\begin{tabular}{|l|l|l|}
\hline$I(A G)=$ & $I(G R)=$ & $I(A G): I(G R)=$ \\
\hline$I(B G)=$ & $I(G Q)=$ & $I(B G): I(G Q)=$ \\
\hline$I(C G)=$ & $I(G P)=$ & $I(C G): I(G P)=$ \\
\hline
\end{tabular}
Observe that all of these ratios are nearly 2 : 1
Construct a quadrilateral PQRS, in which PQ = 4cm, QR = 5cm, $\angle\text{P}=50^\circ,\angle\text{P}=110^\circ$ and $\angle\text{R}=70^\circ.$
→
