Question
Let $\text{X}=\overline{\text{ABC}}+\overline{\text{BCA}}+\overline{\text{CAB}}.$ Evaluate X for:
  1. $\text{A}=1,\text{B}=0,\text{C}=1$
  2. $\text{A}=\text{B}=\text{C}=1$
  3. $\text{A}=\text{B}=\text{C}=0$
✓

Answer

Given,

Output $\text{X}=\overline{\text{ABC}}+\overline{\text{BCA}}+\overline{\text{CAB}}$

  1. $\text{A}=1,\text{B}=0,\text{C}=1$

$\text{X}=1.\Big(\overline{0.1}\Big)+0\Big(\overline{1.1}\Big)+1\Big(\overline1.0\Big)$

$=1.\bar{0}+0.\bar{1}+1.\bar{0}$

$=1.1+0.0+1.1$

$=1+0+1$

$=1+1$

$=1$

  1. $\text{A}=\text{B}=\text{C}=1$

$\text{X}=1\Big(\overline{1.1}\Big)+1\Big(\overline{1.1}\Big)+1\Big(\overline{1.1}\Big)$

$=1.\bar{1}+1.\bar{1}+1.\bar{1}$

$=1.0+1.0+1.0$

$=0+0+0$

$=0$

  1. $\text{A}=\text{B}=\text{C}=0$

$\text{X}=0\Big(\overline{0.0}\Big)+0\Big(\overline{0.0}\Big)+0\Big(\overline{1.1}\Big)$

$=0.\bar{0}+0.\bar{0}+0.\bar{0}$

$=0.1+0.1+0.1$

$=0+0+0$

$=0.$
