Question
Suppose the platform with the kid in the previous problem is rotating in anticlockwise direction at an angular speed $\omega.$ The kid starts walking along the rim with a speed v relative to the platform also in the anticlockwise direction. Find the new angular speed of the platform.
✓

Answer

From a inertial frame of reference when we see the (man wheel) system, we can find that the wheel moving at a speed of $\omega$ and the man with $\Big(\omega+\frac{\text{V}}{\text{R}}\Big)$ after the man has started walking. $(\omega'=$ angular velocity after walking, $\omega=$ angular velocity of the wheel before walking$).$

Since $\sum\text{l}=0$

Extended torque = 0

Therefore, $(1+\text{MR}^2)\omega=\text{l}\omega'+\text{mR}^2\Big(\omega'+\frac{\text{V}}{\text{R}}\Big)$

$\Rightarrow(1+\text{MR}^2)\omega=\text{l}\omega'+\text{mR}^2\omega'+\text{mVR}$

$\Rightarrow\omega'=\omega-\frac{\text{mVR}}{(1+\text{mR}^2)}.$

Need a full question paper?

Generate a complete, print-ready paper with questions like this in minutes — across 16+ boards, with answer keys.

Start Generating Free

Explore more

More "3 Marks Question" from Rotational Mechanics→Rotational Mechanics — all question types→Physics STD 11 Science question papers→Rajasthan Board STD 11 Science question papers→Rajasthan Board question paper generator→

Similar questions

A student records the initial length l, change in temperature $\Delta\text{T}$ and change in length $\Delta\text{l}$ of a rod as follows:
S.NO.
l(m)
$\Delta\text{T(C)}$
$\Delta\text{l}(\text{m})$
1.
2
10
4 × 10-4
2.
1
10
4 × 10-4
3.
2
20
2 × 10-4
4.
3
10
6 × 10-4
If the first observation is correct, what can you say about observations 2, 3 and 4.
→
Calculate the temperature at which r.m.s. velocity of a gas molecule is same as that of a molecule of another gas at 47°C. Molecular weight of first and second gases are 64 and 32 respectively.
→
Why is electrical power required at all when the elevator is descending? Why should there be a limit on the number of passengers in this case?
→
Set up a relation between speed of sound in a gas and root mean square velocity of the molecules of that gas.
→
The radius of curvature of a concave mirror measured by spherometer is given by $\text{R}=\frac{\text{I}^2}{6\text{h}}+\frac{\text{h}}{2}.$ The values of land h are 4cm and 0.065cm respectively. Compute the error in measurement of radius of curvature.
→
Calculate the change in internal energy of a gas kept in a rigid container when 100J of heat is supplied to it.
→
Just as precise measurements are necessary in science, it is equally important to be able to make rough estimates of quantities using rudimentary ideas and common observations. Think of ways by which you can estimate the following (where an estimate is difficult to obtain, try to get an upper bound on the quantity):
The number of air molecules in your classroom.
→
Consider a sunlike star at a distance of 2 parsecs. When it is seen through a telescope with 100 magnification, what should be the angular size of the star? Sun appears to be $\Big(\frac{1}{2}\Big)^0$ from the earth. Due to atmospheric fluctuations, eye can’t resolve objects smaller than 1 arc minute.
→
When the planet Jupiter is at a distance of 824.7 million kilometers from the Earth, its angular diameter is measured to be 35.72” of arc. Calculate the diameter of Jupiter.
→
A spring of constant k is attached with a mass m and is made to oscillate. What is its time period?
→
